Product Details:
|
| Application: | FTTH | Color: | White |
|---|---|---|---|
| Function: | 1GE Port | Product Name: | XPON ONU |
| Power Supply: | 12V 0.5A | Connector Type: | SC/UPC |
| Connector: | RJ45 | PON Port: | SC |
| Wavelength: | 1310/1490nm | Size: | 83 Mm X 69 Mm X 28 Mm |
| Highlight: | 12V 0.5A wifi ont modem,28mm 1490nm wifi ont modem,28mm 1490nm ftth epon ont |
||
Xpon ONU is designed to meet the multi-service needs of fixed network operators or cable operators. It is widely used in FTTO (office), FTTD (desk), FTTH(Home).
EchoLife ONT series products are the home-side devices of Huawei's FTTH solution, and realize ultra-broadband access for home or SOHO users through xPON technology. Provide POTS voice interface and FE/GE adaptive Ethernet interface. The key features of the product are plug and play, remote diagnosis, link monitoring and green energy saving.
By using XPON technology, ultra-broadband access is provided for home and SOHO users. this provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.
| Technical items | Descriptions |
| Fiber port | 1 GPON interface, SC single-mode/single-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps |
| Wavelength | Tx 1310nm, Rx 1490nm |
| Fiber interface | SC/PC |
| RX sensitivity | <-28dBm (1490nm) |
| WLAN | IEEE802.11b/g/n,300Mbps, a built-in antenna |
| LAN | 1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface |
| Throughput | Throughput can reach 900Mbps or more |
| DC power | 12V 1A, external AC-DC power adapter |
| Button | Reset, power |
| Power | ≤8W |
| Operation | Working temperature: -5-+55℃ working humidity:10-90%(non-condensation) |
| Storage | Storage temperature: -30℃-+60℃ storage humidity: 10-90%(non-condensation) |
| Dimension | 130*105*30mm(length*width*height) |
| Net weight | ≤0.3Kg |
Q: Do you have any MOQ limit for sample order?
A: Low MOQ, 1pc for sample checking is available
Q: What’s your best price?
A: Based on the quality of our products and the quantity of your order.we would quote the best matching price all the time.
Q:How to proceed an order for the product?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty to our formal products.
