Huawei Echolife GPON ONU HG8321R FTTH GPON Terminal 1GE+1FE+1POTS Fttx Router Modem

Description

Huawei HG8321R FTTH is an optical network terminal (ONT) with a high-end home Bridge in FTTH solution (2LAN+1POT)

This model features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Therefore, the HG8321R provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.

HG8321R Provide English firmware and EU, US, UK, AU Power adapter for your choice.

Features

• Rich interfaces to meet multiple application scenarios
  Huawei HG8321R FTTH provides multiple interfaces including FE, GE, VoIP, E1, WiFi, RF, USB, etc., to meet the needs of scenarios such as FTTH, FTTB, FTTO and applications for home users and business users.
• Flexible and diverse business support
  It supports the development of large-bandwidth data and Internet access, VoIP, IPTV, CATV video services, and L2VPN services, and provides good QoS and security guarantees.
• Fast deployment and easy operation
  Convenient installation methods and disk fibre design make installation easier. Through the batch configuration operation of the network management system, zero-configuration on-site is achieved.
• Low power consumption, green and energy saving
  The corresponding status monitoring can be performed according to whether the ONT is idle or not, and enter a low power consumption state, which fully reflects the design of green energy saving and emission reduction.
• Fast fault location
  It can track protocol signals and monitor ONT performance to quickly locate equipment faults.

Specification

Detailed Images

FAQ

Q: What is Huawei HG8321R GPON port connector type, SC/APC or SC/UPC?
A: It comes with SC/UPC type.

Q: Can I use Huawei HG8321R with other brand OLT?
A: Not suggested, as the understanding between different vendor on TR069/OMCI may different.

Q: Does Huawei HG8321R support WIFI?
A: No.

Q: How to Restore Factory Settings for Huawei HG8321R?
A: Use either of the following methods to restore factory settings for Huawei HG8321R:
1. Choose System Tools > Restore Default Configuration from the main menu on the web page and click Restore Default Configuration.
2. Hold down the RESET button for a long period of time (longer than 10s) to restart the Huawei HG8321R with factory settings.

Q: What is ONT's optical power range?
A: For the Huawei HG8321R using GPON upstream transmission: -27 dBm to -8 dBm (Class B+); -30 dBm to -8dBm (Class C+).

Q: Can Huawei HG8321R connect to a switch in the lower layer to support the enterprise private line service?
A: No. Huawei HG8321R cannot connect to a PON terminal, switch, or router in the lower layer.

Q: Can an optical port on Huawei HG8321R connect to an optical port on an optical transceiver?
A: No. The optical port on Huawei HG8321R is a PON port while the optical port on an optical transceiver is a GE port.

Q: How to change a digitmap mapping mode of Huawei HG8321R?
A: Choose Voice > VoIP Basic Configuration from the main menu on the web page and configure Digitmap Match Mode.
