Product Details:
|
| Product Name: | Fiber Optic Distribution Box | Material: | 70%PC+30%ABS |
|---|---|---|---|
| Color: | White | Cable Prot: | 4 In 16 Out |
| Dimension: | 231mm*152mm*59mm | Assemmbling Method: | Pole Or Wall-mounting |
| Protection Level: | IP65 | Keywords: | Fiber Optic Distribution Box |
| Number Of Packing: | 10 Pcs/ctn | Highlight: | Fiber Optic Cable Joint Box |
| High Light: | FDB 216A fiber optic junction box,330mm fiber optic junction box,330mm odf box for fiber optic |
||
UT-King’s fiber distribution box (FDB) is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.
| Model | UT-FDB216A |
| Dimension | 295mm*220mm*85mm |
| Color | White,Black or customized |
| Material | 70%PC+30%ABS |
| Max ratio | 1:16 |
| Cable entry ports | In 2 Out 16 |
| Diameter of Cable | Φ13mm |
| Assemmbling method | pole, wall-mounting |
| Protection level | IP65 |
| Outter carton size | 610*510*330mm |
| number of Packing | 10 pcs/ctn |
| weight | 16kg /ctn |
1．Wall-mounted installation
2．Pole-mounted installation
