Product Details:
|
| Application: | FTTH Terminal Box | Color: | Grey |
|---|---|---|---|
| Material: | Aluminum | Product Name: | DIN Termination Box |
| Type: | DIN Rail Mounting | Number Of Cable Entry Points: | 2 |
| Number Of Splice Trays: | 1 | Size: | 130x140.5x45.3 Mm |
| Fiber Core Capacity: | 6 Duplex | ||
| High Light: | 130mm Fiber Optic Terminal Box,ftth S12 Fiber Optic Terminal Box,ftth S12 fiber optic breakout box |
||
UT-King’s DIN Rail Fiber optic terminal box is available for the distribution and terminal connection for various kinds of optical fiber system, especially suitable for mini-network terminal distribution, in which the optical cables, patch cores or pigtails are connected. All of the Din Rail Boxes can be fully populated.
| Type | UT-DIN-SC12 |
| Color | Gray |
| Material | Aluminum |
| Mounting | DIN Rail mounting |
| Number of cable entry points | Number of cable entry points |
| Number of Splice Trays | 1 |
| Weight | 0.5kg |
| Size | 130x140.5x45.3 mm |
| Adapter type | SC Simplex,SC Duplex,LC,FC,ST |
| Fiber core capacity | 12 (single core) |
| Package Dimension | 540*430*350mm |
| Gross Weight | 13.5kg |
| Qty in Carton | 30pcs |
