Product Details:
|
| Application: | Fiber To The Home | Color: | White |
|---|---|---|---|
| Function: | 4FE+2TEL+WIFI | Product Name: | Gpon ONU/ONT |
| Power Supply: | 12V 1A | Connector Type: | SC/UPC |
| Connector: | RJ45 | PON Port: | SC |
| Wavelength: | 1310/1490nm | Weight: | About 0.5 Kg |
| Size: | 265 Mm X 176 Mm X 82 Mm | ||
| High Light: | 1TEL gpon optical network unit,rohs gpon optical network unit,SC 1TEL optical modem ont |
||
Huawei HG8245Q2 FTTH is a routing-type ONT in the Huawei all-optical access solution. It uses GPON technology to implement ultra-broadband access for users. This model offers 4 GE+2 POTS+1 USB+2 WiFi(4 GE ports, 2 POTS ports, 1 USB port, 1 2.4G WiFi port, and 1 5G WiFi port). The high forwarding performance ensures the user experience of voice, data, and HD video services, and provides customers with an ideal all-optical access solution and future-oriented service support capability.
| Model | HG8245Q2 |
| Working environment | Operating temperature: 0ºC to 40ºC |
| Environment humidity: 5% to 95% (noncondensing) | |
| Typical power consumption | 8 W |
| Power specifications | Power adapter input: 100 to 240 V AC, 50–60 Hz |
| System power supply: 11–14 VDC, 2 A | |
| WLAN | 802.11ac |
| Support IPv4 or IPv6 | IPv4 and IPv6 |
| Network-side Port | GPON |
| User-side Ports | 1 x POTS + 4 x GE + 2.4G/5G Wi-Fi + 1 x USB |
| Indicators | POWER/PON/LOS/TEL/LAN/WLAN/WPS/USB |
| Dimensions | 265 mm x 176 mm x 82 mm |
Q: What is the difference between Huawei HG8245Q2 and Huawei HG8546M (GE)?
A: The main difference is Huawei HG8245Q2 comes with 2.4G/5G WiFi, Huawei HG8546M (GE) only 2.4G WiFi. Huawei HG8245Q2 comes with 4GE ports, Huawei HG8546M (GE) with 1GE ports.
Q: Does Huawei HG8245Q2 comes with Europe type adapter?
A: Yes, it comes with EU type adapter.
Q: Does Huawei HG8245Q2 login page is English?
A: Yes, it is English version.
Q: Does Huawei HG8245Q2 with CE label in the back?
A: Yes.
Q: Does Huawei HG8245Q2 interface name in English?
A: Yes.
