Product Details:
|
| Application: | FTTH | Color: | White |
|---|---|---|---|
| Function: | 1GE+3FE+1TEL+USB+WIFI | Product Name: | Gpon ONT |
| Power Supply: | 12V 1.5A | Connector Type: | SC/UPC SC/APC |
| Connector: | RJ45 | PON Port: | SC |
| Wavelength: | 1310/1490nm 1550nm | Size: | 240*160*35mm |
| Weight: | About 0.5 Kg | ||
| High Light: | sc 1GE GPON ONU,1TEL GPON ONU,12V UPC optical fiber wifi router |
||
Huawei HS8545M5 FTTH is a high-end home gateway in FTTH solution. By using GPON technology, ultra-broadband access is provided for home and SOHO users. Huawei HS8545M5 FTTH features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Huawei HS8545M5 FTTH gives a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.
| Brand | Huawei | |
| Model | Huawei HS8545M5 | |
| Power supply | 12V,1.5A | |
| Port | 1GE 3 FE I USB 1POT | |
| WiFi | YES | |
| Power consumption(full loaded) | ≤15W | |
| Outline dimensions(mm) (W*D*H) | 240*160*35mm | |
| Weight (in maximum configuration) | ≤0.5kg | |
| WIFI | Antenna | 2×2, 5dBi external antenna |
| EIRP | Max 25dBm | |
| VoIP | REN | Max 5REN |
| Connector | 1x RJ11 | |
| Ringing | 65V RMS ringing voltage | |
| USB | Max 1A for each port | |
| Environmental requirements | Working temperature:0ºC~50ºC | |
| Storage temperature:-40ºC~70ºC | ||
| Working humidity:5%~90% Storage temperature:5%~95% no condensing | ||
Q:What is Huawei HS8545M5 GPON port connector type, SC/APC or SC/UPC?
A: It comes with SC/UPC type.
Q: Does Huawei HS8545M5 comes with Europe type adapter?
A: Yes, it comes with EU type adapter.
Q: Can I use Huawei HS8545M5 with other brand OLT?
A: Not suggested, as the understanding between different vendor on TR069/OMCI may different.
Q: Does Huawei HS8545M5 support WIFI?
A: Yes, it supports.
Q: Does Huawei HS8545M5 support routing function?
A: Yes.
Q: Does Huawei HS8545M5 support battery backup?
A: No.
Q: How to Restore Factory Settings for Huawei HS8545M5?
A: Use either of the following methods to restore factory settings for Huawei HS8545M5:
1. Choose System Tools > Restore Default Configuration from the main menu on the web page and click Restore Default Configuration.
2. Hold down the RESET button for a long period of time (longer than 10s) to restart the Huawei HS8545M5 with factory settings.
Q: How to configure the Wi-Fi service on Huawei HS8545M5?
A: Configure the Wi-Fi service through web pages or TR069 servers for Huawei HS8545M5 that supports Wi-Fi. For details, see the user manual of Huawei HS8545M5 device.
