Internet Onus FTTH Epon Onu Hardware Gpon 5ghz 4 Port 1ge+3fe+1tel+Wifi Onu

Internet Onus FTTH Epon Onu Hardware Gpon 5ghz 4 Port 1ge+3fe+1tel+Wifi Onu
Internet Onus FTTH Epon Onu Hardware Gpon 5ghz 4 Port 1ge+3fe+1tel+Wifi Onu Internet Onus FTTH Epon Onu Hardware Gpon 5ghz 4 Port 1ge+3fe+1tel+Wifi Onu

Large Image :  Internet Onus FTTH Epon Onu Hardware Gpon 5ghz 4 Port 1ge+3fe+1tel+Wifi Onu

Product Details:
Place of Origin: Guangdong, China
Brand Name: UT-King
Certification: ROHS/ ISO9001 /CE/FCC
Model Number: XP6411
Payment & Shipping Terms:
Minimum Order Quantity: 100 pieces
Price: $15.00/pieces 100-999 pieces
Packaging Details: 1set/box
Supply Ability: 1000 Piece/Pieces per Week
Contact Now

Internet Onus FTTH Epon Onu Hardware Gpon 5ghz 4 Port 1ge+3fe+1tel+Wifi Onu

Description
Type: ONU Use: FTTH, FTTH
Network: Wireless Lan, Wired LAN, Wifi Product Name: XPON ONU
Ports: 1GE+3FE+1TEL+WIFI Down Link LAN Interface: EPON/GPON
Wavelength: Tx 1310nm, Rx1490nm Power Supply: 12V 1A
Color: White Setup Interface: English
MOQ: 1PCS
High Light:

Rx1490nm FTTH Epon Onu

,

ROHS FTTH Epon Onu

,

12V 1A Xpon Onu

FTTH Epon Onu Internet Onus Hardware Gpon 5ghz 4 Port 1ge+3fe+1tel+Wifi Onu Xpon Onu



XPON ONU(UT-XP6421) is designed and manufactured by Shenzhen UT-King Technology Co.,Ltd, a next-generation Gigabit Passive Optical Network terminal, ideal for Fiber to The Home solution. It’s an incredibly robust device allowing users to access high-speed internet connections via its XPON port and share it with a Gigabit Ethernet port. With the transmission rates of up to 2.488Gbps, one XPON port and one Gigabit Ethernet port, It provides high-performance forwarding capabilities to ensure smooth VoIP, HD video streaming experiences.

【Product Feature】
*Complies with ITU G.984.1, ITU G.984.2, ITU G.984.3 and ITU G.984.4 provides comprehensive EPON network compatibility *Downstream rates of up to 2.488Gbps and upstream rates up to 1.244Gbps *Support rich QinQ VLAN functions and IGMP Snooping multicast features. *Fiber access and gigabit port provide incredibly fast transfer speeds *Supports OMCI (ONU Management Control Interface) remote management

【Package Contents】
*1 Port Gigabit EPON Terminal *RJ-45 Ethernet Cable *Quick Installation Guide *Power Adapter

Internet Onus FTTH Epon Onu Hardware Gpon 5ghz 4 Port 1ge+3fe+1tel+Wifi Onu 0

Model
Configuration





Fiber interface

PON
LAN
Telephone
Wifi
CATV

XP6411
1
4
1
2
/
SC UPC


Remarks
Power plug:EU,AU,AM,UK etc






Noted: with English manual






Optional: 1GE+3FE+1POTS+WIFI





Technical item
Specification
PON Interface
1 XPON interface,Downstream rate 2.5Gbps,Upstream rate 1.25Gbps
LAN Interface
1 x 10/100/1000Mbps(GE) and 3 x 10/100Mbps(FE) auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
Wireless
2T2R,2 external antenna 5dB
POTS interface
1* FXS, RJ11 connector
Support: G.711/G.723/G.726/G.729 codec
Support: T.30/T.38/G.711 Fax mode, DTMF Relay Line testing
Operation Condition
Working temperature: -5-+55℃ working humidity:10-90%(non-condensation)
Storing Condition
Storage temperature: -30℃-+60℃ storage humidity: 10-90%(non-condensation)
Capability
Support NAT/PPPOE/DHCP/Static IP/Bridge WAN
Wavelength
TX: 1310nm, RX: 1490nm
DC power
12V DC input
Dimension
180mm×107mm×28mm(L×W×H)

Internet Onus FTTH Epon Onu Hardware Gpon 5ghz 4 Port 1ge+3fe+1tel+Wifi Onu 1



FAQ



1. Can we get a lower price? Any Discount?
Yes, price is not a problem, everything could be negotiated based on the quantity.

2. Can I get a free sample?
Yes,send inquiry,you will get free sample.

3. We are new in this PON fields, can you help me and recommend me some items?
Yes, of course. It is our pleasure to help you with it.
You only need to offer us more details about your application.

4. What is your MOQ?
No MOQ for any sample test.

5. OEM/ODM Service is available?
Yes, we have strong ability to offer customers ODM&OEM products of highest quality.
And it will require the MOQ.

6. For Trade Terms, such as payment and leadtime.
* Payment Terms: We mainly support T/T bank transfer,Paypal and Western Union
* Price Terms: EXW FOB CIF Shenzhen
* Shipping Methods: EMS, DHL, Fedex, TNT, UPS, by sea or your own shipping agent
* Leadtime: Sample order 3-7work days; Bulk order 15-25work days(after your payment)

7. How about the Warranty?
There are 1 Year for the warranty.
While the warranty is not responsible for those broken by violence or updated with other brands.
