HGU GPON Dual Band ONU ONT Router 2x5 Dbi WIFI 4GE+1POTS+2WIFI 2.4g 5.8g

HGU GPON Dual Band ONU ONT Router 2x5 Dbi WIFI 4GE+1POTS+2WIFI 2.4g 5.8g
HGU GPON Dual Band ONU ONT Router 2x5 Dbi WIFI 4GE+1POTS+2WIFI 2.4g 5.8g HGU GPON Dual Band ONU ONT Router 2x5 Dbi WIFI 4GE+1POTS+2WIFI 2.4g 5.8g

Large Image :  HGU GPON Dual Band ONU ONT Router 2x5 Dbi WIFI 4GE+1POTS+2WIFI 2.4g 5.8g

Product Details:
Place of Origin: Guangdong, China
Brand Name: UT-King
Model Number: GP4483
Payment & Shipping Terms:
Minimum Order Quantity: 100 pieces
Price: $17.00/pieces 100-999 pieces
Packaging Details: 1pcs/box
Supply Ability: 1000 Piece/Pieces per Week
Contact Now

HGU GPON Dual Band ONU ONT Router 2x5 Dbi WIFI 4GE+1POTS+2WIFI 2.4g 5.8g

Description
Type: ONU Use: FTTX
Network: Wireless Lan, Wired LAN, Wifi Product Name: GPON ONU
MOQ: 1Piece Distance: 0~ 20Km Max
Color: White PON Interface: 1 SC/UPC Port
RX Sensitivity: < -28dBm @ 1490nm External Power Supply: DC 12V/1A
POTS Interface: 1 FXS, RJ11 Connectors Weight (Full-Loaded): ≤0.4kg
Application: PON Networks Port: Shenzhen,Hongkong,Guangzhou
High Light:

IPv6 ONU ONT Router

,

2.4g ONU ONT Router

,

5.8g GPON ONU

HGU GPON Dual Band WIFI ONT 4GE+1POTS+2WIFI 2.4g&5.8g ONU ONT Compatible with EG8141A5


【Product】
GPON ONU(UT-GP4483) is designed and manufactured by Shenzhen UT-King Technology Co.,Ltd, a next-generation Gigabit Passive Optical Network terminal, ideal for Fiber to The Home solution. It’s an incredibly robust device allowing users to access high-speed internet connections via its XPON port and share it with a Gigabit Ethernet port. With the transmission rates of up to 2.488Gbps, one GPON port and one Gigabit Ethernet port, It provides high-performance forwarding capabilities to ensure smooth VoIP, HD video streaming experiences.
GP4483 is designed as HGU (Home Gateway Unit) in different FTTH solutions. The carrier-class FTTH application provides different services access. * GP4483 is based on mature and stable, cost-effective GPON technology. * GP4483 adopts high reliability, easy management, configuration flexibility and good quality of service guarantees to meet the technical performance of GPON Standard of China Telecom CTC3.0 and GPON Standard of ITU-TG.984.X.

【Product Feature】
* Support Route mode for PPPoE/IPoE/Static IP and Bridge mode
* Support IPv4 and IPv6 Dual mode
* Support 2.4G WIFI and 2*2 MIMO
* Support SIP Proctolfor Voip Service
* Support LAN IP and DHCP Server configuration
* Support Port Mapping and Loop-Detect
* Support Firewall function and ACL function
* Support IGMP Snooping/Proxy multicast feature
* Support TR069 remote configuration and maintenance
* Specialized design for system breakdown prevention to maintain stable system

【Package Contents】 - 1 GPON Terminal - Quick Installation Guide - Power Adapter

Model
Configuration





Fiber interface

PON
LAN
Telephone
Wifi
CATV

EG8141A5
1
4
1
2
/
SC UPC/APC


Remarks
Power plug:EU,AU,AM,UK etc






Noted: with English manual






Optional: 4GE+1POTS+WIFI





Technical item
Specification
PON Interface
1 GPON interface,Downstream rate 2.5Gbps,Upstream rate 1.25Gbps
LAN Interface
4 x 10/100/1000Mbps(GE)  auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
Tel Interface
1pots
WIFI
2pcs antenna
Operation Condition
Working temperature: -5-+55℃ working humidity:10-90%(non-condensation)
Storing Condition
Storage temperature: -30℃-+60℃ storage humidity: 10-90%(non-condensation)
Capability
Support NAT/PPPOE/DHCP/Static IP/Bridge WAN
Wavelength
TX: 1310nm, RX: 1490nm
DC power
12V DC input
Dimension
180mm×140mm×20mm

HGU GPON Dual Band ONU ONT Router 2x5 Dbi WIFI 4GE+1POTS+2WIFI 2.4g 5.8g 0

FAQ
1. Can we get a lower price? Any Discount?
Yes, price is not a problem, everything could be negotiated based on the quantity.

2. Can I get a free sample?
Yes,send inquiry,you will get free sample.

3. We are new in this PON fields, can you help me and recommend me some items?
Yes, of course. It is our pleasure to help you with it.
You only need to offer us more details about your application.

4. What is your MOQ?
No MOQ for any sample test.

5. OEM/ODM Service is available?
Yes, we have strong ability to offer customers ODM&OEM products of highest quality.
And it will require the MOQ.

6. For Trade Terms, such as payment and leadtime.
* Payment Terms: We mainly support T/T bank transfer,Paypal and Western Union
* Price Terms: EXW FOB CIF Shenzhen
* Shipping Methods: EMS, DHL, Fedex, TNT, UPS, by sea or your own shipping agent
* Leadtime: Sample order 3-7work days; Bulk order 15-25work days(after your payment)

7. How about the Warranty?
There are 1 Year for the warranty.
While the warranty is not responsible for those broken by violence or updated with other brands
