Product Details:
|
| Product Name: | XPON ONU | Brand: | UT-King |
|---|---|---|---|
| Function: | 1ge+3fe+1tel+CATV+wifi | Wavelength: | Tx 1310nm, Rx1490nm |
| Name: | XPON ONU | Applications Distance: | 20km |
| Chipset: | RTL/ZTE/MTK | External Power Supply: | DC 12V/1A |
| Optical Interface: | SC APC | ||
| High Light: | ftth HGU XPON ONU,ftth DC 12V XPON ONU,DC 12V gpon epon onu modem |
||
UT-XP6442 series is designed as HGU(Home Gateway Unit) in deferent FTTH solutions by UT-King, Thecarrier-class FTTH application provides data service access, based on mature and stable, cost-effective XPON technology. It can switchautomatically with EPON and GPON when it access to the EPON OLT or GPON OLT.XPON series adopts high reliability, easy management, configuration flexibility and good quality ofservice (QoS) guarantees to meet the technical performance of the module of China Telecom EPONCTC3,0 and GPON Standard of ITU-TG.984.X. UT-XP6442 is designed by Realtek chipset 9603C.
| Item |
|
||||||||
|
PON Interface
|
|
||||||||
| Wavelength | TX: 1310nm, RX: 1490nm | ||||||||
| Optical Interface | SC/APC Connector | ||||||||
| POTS interface |
1* FXS, RJ11 connector Support: G.711/G.723/G.726/G.729 codec Support: T.30/T.38/G.711 Fax mode, DTMF Relay Line testing according to GR-909 |
||||||||
| LAN Interface | 1 * 10/100/1000Mbps and 3 * 10/100Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector | ||||||||
| CATV interface |
|
||||||||
| Wireless |
|
||||||||
| LED | 12, For Status of POWER,LOS,PON,SYS,LAN1,LAN2,WIFI,WPS,Internet,FXS,Worn,Normal(CATV) | ||||||||
| Push-Button | 3,For Function of Reset,WLAN,WPS | ||||||||
| Operating Condition |
|
||||||||
| Storing Condition |
|
||||||||
| Power Supply | DC 12V/1A | ||||||||
| Power Consumption | ≤6W | ||||||||
| Dimension | 155mm×92mm×34mm(L×W×H) | ||||||||
| Net Weight | 0.24kg |
