Product Details:
|
| Insertion Loss: | ≤0.2db | Application: | FTTH FTTB FTTX Network |
|---|---|---|---|
| Connector Type: | SC | Return Loss: | Upc≤45db,Apc≤55db |
| Color: | Green/Blue | Product Name: | SC Fast Connector |
| Fiber Type: | SM | Operating Temperature: | -40 To +85 Degree |
| Durability: | ≤ 0.25db Typical Change | Certification: | ISO9001,RoHS,CE,SGS |
| Name: | Fast Connector | Connector: | Fast Connector SC |
| Fiber Cable Type: | 3x2mm Flat Cable | Length: | 60mm |
| High Light: | RoHS 60mm sc lc connector,RoHS sc lc connector,60mm apc fiber connector |
||
It is widely used in FTTH project,as well as fiber optic transmission lines, fiber optic distribution frames and fiber optic testing instruments
We are here to supply the most exclusive product at reasonable prices. Also, our FC field assembly connector is famous by the first-class features especially efficiency and user-friendliness.
A pre-polished ferrule in our fast connector is suitable for the couple the fiber and ensure low loss because of the proprietary gel. As a result, our clients feel convenient while assembling this fast connector. They feel satisfied with the strong stability of this product.
| Model No. | UT-SC6004 |
| Connector Type | UPC/APC |
| Length | 60mm |
| Applicable for | Drop cable.Indoor cable |
| Fiber mode | Single mode or Multi mode |
| Operation time | About 50s(no fiber cut) |
| Insertion Loss | ≤0.2dB |
| Insertion Loss Typical value | 0.2dB |
| Return Loss | ≥50dB UPC ≥55dB APC |
| Fastening strength of naked fiber | ≥5N |
| Tensile strength | ≥50N |
| Reusable | ≥10 times |
| Operating Temperature | -40～+85℃ |
