Product Details:
|
| Product Name: | XPON ONU | Brand: | UT-King |
|---|---|---|---|
| Function: | 4ge+2tel+2.4G&5.8G Wifi | Wavelength: | Tx 1310nm, Rx1490nm |
| Name: | XPON ONU | Applications Distance: | 20km |
| Chipset: | RTL/ZTE/MTK | External Power Supply: | DC 12V/1.5A |
| Optical Interface: | SC UPC/SC APC | LAN Interface: | 4*10/100/1000Mbps RJ45 Ports |
| Size: | 155mm×92mm×34mm（L×W×H） | ||
| High Light: | 5.8g 2GE CATV XPON ONU,ftth 5.8g upc USB XPON ONU,upc USB ftth gpon epon onu |
||
UT-XP6241 seriess the device terminal for ONT in the XPON system, cooperating with OLT. ONT can provide various broadband services to the connected users, such as Internet, VoIP, IPTV, Video Conference and other businesses.It provides a PON interface, 2 10/100/1000m adaptive Ethernet ports, and a USB interface based on mature, stable, cost-effective GPON technology.Single fiber WDM technology (down 1490nm, up 1310nm) is adopted to connect only one fiber to OLT, and the maximum transmission distance is up to 20km. It supports the power down and report function and supports the local WEB management function.
| Item | |||||||||||||
PON Interface
|
| ||||||||||||
| Wavelength | TX: 1310nm, RX: 1490nm | ||||||||||||
| Optical Interface | 1* SC/APC Connector or 1* SC/UPC Connector | ||||||||||||
| POTS interface | 2* FXS, RJ11 connector | ||||||||||||
| LAN Interface | 4*10/100/1000Mbps RJ45 Ports | ||||||||||||
| Wireless |
| ||||||||||||
| Push-Button | 3,For Function of Reset,WLAN,WPS | ||||||||||||
| Operating Condition |
| ||||||||||||
| Storing Condition |
| ||||||||||||
| Power Supply | DC 12V/1.5A | ||||||||||||
| Power Consumption | ≤8 W | ||||||||||||
| Dimension | 155mm×92mm×34mm(L×W×H) | ||||||||||||
| Net Weight | 0.24kg | ||||||||||||
| Ethernet Interface | 4x 10/100/1000BASE-T RJ45 | ||||||||||||
| XPON | Speed | Downstream:2.488Gbps | |||||||||||
| Connector | SC/UPC, pigtail,G.652 Single Mode Fiber | ||||||||||||
| Power level | Downstream: | ||||||||||||
| WIFI | Standard | ThroughPut (11n HT40): ≥140Mbps | |||||||||||
| Antenna | 2.4G antenna :4dBi | ||||||||||||
| VoIP | Connector | 2 * RJ11 | |||||||||||
| Ringing | 65V RMS ringing voltage | ||||||||||||
| USB | Max 1A for each port | ||||||||||||
Detailed Images
Q: Can I have a sample order for this product?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q: What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q: Do you have any MOQ limit for sample order?
A: Low MOQ, 1pc for sample checking is available
Q: What’s your best price?
A: Based on the quality of our products and the quantity of your order.we would quote the best matching price all the time.
Q: Can you provide OEM/ODM service?
A: Yes,we can.Please let us know your deatil requirements.
Q: How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
