Product Details:
|
| Type: | ONU | Use: | FTTH FTTB FTTX |
|---|---|---|---|
| Warranty Time: | 1Year | Network: | Wireless Lan, Wired LAN, Wifi |
| Product Name: | XPON ONU | Enternet Ports: | 1GE |
| Chipset: | Hislicon Chipset | Color: | White |
| Connector Type: | SC/UPC SC/APC | Power Supply: | 12V 0.5A |
| Keywords: | Ont Xpon | ||
| High Light: | FTTX Solution XPON ONU,Mini Type XPON ONU Bridge,Oem XPON ONU Bridge |
||
Bridge Indoor network Unit Oem FTTX Solution GEPON ONU with 1GE Mini Type XPON ONU Bridge
XPON ONU(UT-XP6105) is designed and manufactured by Shenzhen UT-King Technology Co.,Ltd, a next-generation Gigabit Passive Optical Network terminal, ideal for Fiber to The Home solution. It’s an incredibly robust device allowing users to access high-speed internet connections via its XPON port and share it with a Gigabit Ethernet port. With the transmission rates of up to 2.488Gbps, one XPON port and one Gigabit Ethernet port, It provides high-performance forwarding capabilities to ensure smooth VoIP, HD video streaming experiences.
UT-King 1ge xpon onuseries is based on mature and stable, cost-effective XPON technology. It can switch automatically with EPON and GPON when it access to the EPON OLT or GPON OLT
Features
* Support EPON/GPON mode and switch mode automatically
* Support ONU auto-discovery/Link detection/remote upgrade of software
* Support RoutePPPoE/IPoE/Static IP and Bridge mode
* Support IPv4/IPv6 Dual mode
* Support Firewall function and IGMP multicast feature
* Support LAN IP and DHCP Server configuration
* Support Port Forwarding and Loop-Detect
* Support TR069 Remote Configuration and maintenance
* Specialized design for system breakdown prevention to maintain stable system
|
Model |
Configuration |
|
|
|
|
Fiber interface |
|||||||||||
|
|
PON |
LAN |
Telephone |
Wifi |
CATV |
|
|||||||||||
|
XP6105 |
1 |
1GE |
/ |
/ |
/ |
SC UPC |
|||||||||||
|
Remarks |
Power plug:EU,AU,AM,UK etc |
|
|
|
|
|
|||||||||||
|
|
Noted: with English manual |
|
|
|
|
|
|||||||||||
|
|
Optional: 1GE Single Port XPON ONU |
|
|
|
|
|
|||||||||||
|
Module |
XP6105 |
|
User |
1 10/100/1000M RJ45 port. |
|
|
Transmission speed :upstream 1.25Gbps /downstream 2.5Gbps |
|
|
Compliant with IEEE 802.3ah |
|
|
Support NAT Support PPPOE |
|
|
Port-based VLAN GVRP |
|
|
Backpressure flow control(half-duplex) IEEE 802.3x flow control(full-duplex) |
|
|
IEEE 802.1x, access control based upon Port; support local and remote RADIUS. CHAP,EAP certification; |
|
|
Various management modes such as Web, TELNET Debug function. |
|
Size |
105mm(L) ×85mm(W) ×25mm(H) |
|
|
Operating temperature:0℃~60℃; |
|
|
Storage temperature:-40℃~80℃; |
|
|
110~240VAC 12V/0.5A DC |
|
Power |
|
1. Can we get a lower price? Any Discount?
Yes, price is not a problem, everything could be negotiated based on the quantity.
2. Can I get a free sample?
Yes,send inquiry,you will get free sample.
3. We are new in this PON fields, can you help me and recommend me some items?
Yes, of course. It is our pleasure to help you with it.
You only need to offer us more details about your application.
4. What is your MOQ?
No MOQ for any sample test.
5. OEM/ODM Service is available?
Yes, we have strong ability to offer customers ODM&OEM products of highest quality.
And it will require the MOQ.
6. For Trade Terms, such as payment and leadtime.
* Payment Terms: We mainly support T/T bank transfer,Paypal and Western Union
* Price Terms: EXW FOB CIF Shenzhen
* Shipping Methods: EMS, DHL, Fedex, TNT, UPS, by sea or your own shipping agent
* Leadtime: Sample order 3-7work days; Bulk order 15-25work days(after your payment)
7. How about the Warranty?
There are 1 Year for the warranty.
While the warranty is not responsible for those broken by violence or updated with other brands.
