Product Details:
|
| Type: | ONU | Use: | FTTH FTTB FTTX |
|---|---|---|---|
| Network: | Wireless Lan, Wired LAN | Product Name: | GPON ONU/ONT |
| Function: | 1GE +1FE+1POT | Optical Interface: | SC/APC |
| Firmware: | English | Color: | White |
| Material: | Plastic | Dimensions: | 30 Mm X 115 Mm X 94 Mm |
| Power Supply: | DC 11V-14V, 1.5A | Keywords: | Huawei Gpon Ont |
| High Light: | 1.5A XPON ONT Modem,DC11V XPON ONT Modem,XPON Indoor ONU Switch |
||
FTTH Fiber XPON ONT Modem With 1GE +1FE+1POTS UT-King EG8120L XPON Indoor ONU Switch
【About Product】
XPON ONU(UT-XP6211) HW EG8120L FTTH is an intelligent routing-type ONT with one GE port, one POTS port, and one FE port. EG8120L gives high-performance service forwarding capabilities to ensure excellent experiences with VoIP, Internet, and HD video services. This provides a perfect terminal solution and future-oriented service-supporting capabilities for networks.through the high-performance forwarding ability to effectively guarantee the service experience of data and high-definition video, to provide FTTH deployment Ideal terminal solutions and future-oriented service support capabilities.
| Brand | UT-King |
| Model | EG8120L |
| Dimensions (H x W x D) | 30 mm x 115 mm x 94 mm |
| Weight | About 155g |
| Operating Temperature | 0°C to +40°C |
| Operating Humidity | 5% RH to 95% RH (non-condensing) |
| Power Adapter Input | 100V to 240V AC, 50/60 Hz |
| System Power Supply | 11V to 14V DC, 1A |
| Static Power Consumption | 3.8W |
| Maximum Power Consumption | 4.9W |
| Ports | 1 POTS + 1 GE + 1 FE |
| Indicators | POWER/PON/LOS/LAN/TEL |
【Product Feature】
1.Complies with ITU-T984.1, ITU-T G.984.2, ITU-T G.984.3 and ITU-T G.984.4 provides comprehensive GPON network compatibility
2.Downstream rates of up to 2.488Gbps and upstream rates up to 1.244Gbps
3.Fiber access and gigabit port provide incredibly fast transfer speeds
4.Supports OMCI (ONU Management CONUrol Interface) remote management
|
Model |
Configuration |
|
|
|
|
Fiber interface |
|||||||||||
|
|
PON |
LAN |
Telephone |
Wifi |
CATV |
|
|||||||||||
|
EG8120L |
1 |
2 |
1 |
internal |
/ |
SC UPC/APC |
|||||||||||
|
Remarks |
Power plug:EU,AU,AM,UK etc |
|
|
|
|
|
|||||||||||
|
|
Noted: with English manual |
|
|
|
|
|
|||||||||||
|
|
Optional: 1GE+1FE+1POTS |
|
|
|
|
|
|||||||||||
