Product Details:
|
| Type: | ONU | Use: | FTTH |
|---|---|---|---|
| Warranty Time: | 1 Year | Network: | Wireless Lan, None, Wifi |
| Application: | FTTH FTTX | Product Name: | XPON ONU |
| Function: | 1GE+1FE+1TEL+WIFI | Input Power: | 12V 1A |
| Connector Type: | SC/UPC SC/APC | Wavelength: | Tx 1310nm, Rx1490nm |
| Chipset: | ZTE/RTL/MTK | LAN Interface: | 1 X 10/100/1000Mbps |
| Software: | English Firmware | Keywords: | ONU XPON |
| High Light: | Wifi Ont Bridge Modem,XPON ONU 12V 1A,Telephone FTTH ONU |
||
|
Model
|
Configuration
|
|
|
|
|
Fiber interface
|
|||||
|
|
PON
|
LAN
|
Telephone
|
Wifi
|
CATV
|
|
|||||
|
XP6222
|
1
|
2
|
/
|
1
|
/
|
SC UPC/APC
|
|||||
|
Remarks
|
Power plug:EU,AU,AM,UK etc
|
|
|
|
|
|
|||||
|
|
Noted: with English manual
|
|
|
|
|
|
|||||
|
|
Optional: 1GE+1FE+WIFI ONU
|
|
|
|
|
|
|||||
|
Technical item
|
Specification
|
|
PON Interface
|
1 XPON interface,Downstream rate 2.5Gbps,Upstream rate 1.25Gbps
|
|
LAN Interface
|
1 x 10/100/1000Mbps(GE) and 1 x 10/100Mbps(FE) auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
|
|
Wireless
|
Compliant with IEEE802.11 a/b/g/n/ac WiFi, 4T4R external antenna, 2.4GHz Operating frequency: 2.400-2.483GHz5.0GHz Operating
frequency: 5.150-5.825GHzSupport MIMO, rate up to 1.167Gbps |
|
Network Management
|
Support Remote management through SNMP and Telnet ; Local management
|
|
Operation Condition
|
Working temperature: -5-+55℃ working humidity:10-90%(non-condensation)
|
|
Storing Condition
|
Storage temperature: -30℃-+60℃ storage humidity: 10-90%(non-condensation)
|
|
Capability
|
Support NAT/PPPOE/DHCP/Static IP/Bridge WAN
|
|
Wavelength
|
TX: 1310nm, RX: 1490nm
|
|
DC power
|
12V DC input
|
|
Dimension
|
180mm×120mm×30mm(L×W×H)
|
