Product Details:
|
| Type: | ONU | Use: | FTTH |
|---|---|---|---|
| Warranty Time: | 1 Years | Network: | Wireless Lan, Wifi |
| Chipset: | RTL9607C+RTL8192+RTL8812 | Interface: | SC/UPC |
| Product Name: | ONU | Ports: | 1ge+3fe+wifi Xpon Onu |
| Wavelength: | Tx 1310nm, Rx1490nm | Dimension: | 185mm*140mm*30mm |
| Power Supply: | DC 12V/1A | Wifi: | 5db |
| Color: | White | ||
| High Light: | DC 12V XPON ONT,FTTH Solutions XPON ONT,Xpon Onu With Wifi Router |
||
|
Model
|
Configuration
|
|
|
|
|
Fiber interface
|
|||||
|
|
PON
|
LAN
|
Telephone
|
Wifi
|
CATV
|
|
|||||
|
XP6411
|
1
|
4
|
1
|
2
|
/
|
SC UPC/APC
|
|||||
|
Remarks
|
Power plug:EU,AU,AM,UK etc
|
|
|
|
|
|
|||||
|
|
Noted: with English manual
|
|
|
|
|
|
|||||
|
|
Optional: 1GE+3FE+1POTS+WIFI+1USB
|
|
|
|
|
|
|||||
|
Technical item
|
Specification
|
|
PON Interface
|
1 XPON interface,Downstream rate 2.5Gbps,Upstream rate 1.25Gbps
|
|
LAN Interface
|
1 x 10/100/1000Mbps(GE) and 3 x 10/100Mbps(FE) auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
|
|
Chipsets
|
Realtek
|
|
WLAN
|
Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R two external antenna
|
|
Operation Condition
|
Working temperature: -5-+55℃ working humidity:10-90%(non-condensation)
|
|
Storing Condition
|
Storage temperature: -30℃-+60℃ storage humidity: 10-90%(non-condensation)
|
|
POTS Interface
|
2 FXS, RJ11 connectors
|
|
Wavelength
|
TX: 1310nm, RX: 1490nm
|
|
DC power
|
12V DC input
|
|
Dimension
|
200mm×140mm×40mm(L×W×H)
|
